Heavy Hammer Crusher

Application Areas: Suitable for mining, cement, coal, building materials, combustion and so on

≤2000mm
Feed Size
132-450kw
Motor Power
100-1200t/h
Capacity
Heavy Hammer Crusher
60S Quick response
30 min Technical reply
24h design proposal
365 days to receive service needs
  1. Heavy Hammer Crusher
  2. Heavy Hammer Crusher
  3. Heavy Hammer Crusher
  4. Heavy Hammer Crusher
Heavy Hammer Crusher of Description

The PCZ series heavy-duty hammer crusher is a new type of crusher developed based on the PC series crusher, user feedback information, and the development trends of the crushing industry, and combined with our company's experimental data. Compared with other hammer crushers, the alloy composite hammer head has significant features such as high hammer head wear resistance, large rotational inertia, and high rotor kinetic energy. It has a large feed particle size, high crushing ratio, and low maintenance cost. With an output of 50 tons to 5,000 tons per hour, this series of crushers is becoming the first choice equipment in the crushing industry.

Product Advantage

Product Advantage

1. This heavy-duty hammer crusher has the characteristics of high output, low energy consumption, simple structure and easy maintenance.

2. Compared with jaw crushers of the same output, it can reduce equipment investment, with low investment and quick results.

3. The machine adopts a no-grate design, eliminating the risk of clogging and adhesion for wet materials and crushing materials containing a lot of soil.

4. This machine uses an alloy composite hammerhead, which reduces the consumption of worn parts and reduces production costs by about 35%.


Product Gallery
Product Gallery

Crushed product size

Have Any Questions!

Don't Hesitate To Contact Us AnyTime.






Working Principle

Working principle

The heavy hammer crusher can be formed at one time without secondary crushing and shaping process, which can reduce the cost by about 40%. It has the advantages of large crushing ratio, high output, uniform particle size of finished products, low energy consumption and high environmental protection.

Specification

*The output will vary according to different materials, feed particle size and other factors

Model

Rotor Diameters Length(mm)

Feed Inlet Size(mm)

Processing Capacity(t/h)

Motor Power(kw)

Dimensions(mm)

PC1213

1200×1280

1350×920

300-350

160×2

2970×2580×2510

PC1216

1200×1590

1530×920

400-500

200×2

3070×2840×2580

PC1220

1220×1950

2000×920

500-600

220×2

3080×3380×2580

PCZ1308

1310×790

850×800

100-160

132

2818×2155×2388

PCZ1510

1500×950

1000×900

160-210

132×2

3260×2414×2750

PCZ1512

1500×1160

1200×900

250-320

160×2

3260×2624×2750

PCZ1615

1650×1452

1500×1200

420-500

200×2

3667×2937×3436

PCZ1620

1660×1900

2000×1200

800-1000

400×2

3667×3200×3436

PCZ1820

1800×1964

2000×1200

1000-1200

450×2

3700×3270×3515
