ANSHUN MACHINERY knows what you expect from a mining project, and we are making it happen with unrivaled products and services.
Leave Message
Application Areas: Grading and Screening Materials In Mining, Gravel Fields, Building Materials, Water Conservancy And Hydropower, Transportation, Chemical Industry, Smelting And Other Industries.
The YK series circular vibrating screen is screening equipment with an internationally advanced level developed by our company based on traditional screening machines and the introduction of advanced foreign technology.
Double Shaft Thin Oil Vibrating Screen has a long material screening line, screening specifications, strong vibration force, high screening efficiency, low vibration noise, durability, easy maintenance, safe to use, and so on.
Have Any Questions!
Don't Hesitate To Contact Us AnyTime.
Double Shaft Thin Oil Vibrating Screen adopts a simplified eccentric shaft exciter level bias block to adjust the amplitude through the body's circular movement to achieve the effect of material screening.
Model | Screen Spec (mm) | Layers | Screen Mesh Size(mm) | Feed Size(mm) | Power(t/h) | Capacity (kW) | Vibrating Frequency(Hz) | Double Amplitude |
3YK-3070 | 7000×3000 | 3 | 5-150 | ≤100 | 180-1000 | 2×37 | 800-900 | 7-12 |
3YK-3075 | 7500×3000 | 3 | 5-150 | ≤100 | 210-1100 | 2×37 | 800-900 | 8-12 |
3YK-3680 | 8000×3600 | 3 | 5-150 | ≤100 | 350-1400 | 2×45 | 800-900 | 8-12 |
